AccentPDIR GLF Series Multi-Jet Water Meter

Features

• Certified to NSF/ANSI 61
• 105°F (40°C) maximum temperature
• 150psi maximum operating pressure
• Materials:
  • Body: EcoBrass bronze alloy
  • Internals: Engineered thermoplastic
  • Magnet: Alnico
• ±1.5% of reading accuracy within Qt-Qmax
• Reed switch sensor
• 20mA maximum current
• 24Vdc or Vac maximum voltage
• 12ft (4m) standard cable (2000ft max run)

The AccentPDIR GLF Series multi-jet water meter uses the widely accepted multi-jet principle. The GLF meter’s gear train drives the register totalizer dials. For pulse output meters, a reed switch sensor is attached to the outside of the lens and detects a magnet arm that has replaced one of the dial pointers. The reed switch output is a dry contact closure and does not require power.
