Crowcon DetectiveIQ is a transportable area gas monitor that detects up to 7 gases. It has a 101+ day battery life, modular plug-and-play sensor trays that can be swapped onsite, and Bluetooth connectivity.
Crowcon DetectiveIQ Area Gas MonitorThe Crowcon DetectiveIQ is a rugged, transportable multi-gas area monitor that takes site safety to the next level. It is designed to detect up to seven gases simultaneously and features pull-in, pull-out pre-calibrated modular sensor trays that can be swapped in seconds, dramatically reducing downtime and simplifying maintenance. A powerful 95dB alarm and highly visible 360° LED beacons make hazards unmistakable even in noisy or low-light environments. The unit offers an industry-leading 101+ days of battery life on a single charge, plus optional 30m pump capability for remote sampling. Built for quick servicing, the DetectiveIQ’s outer casing, boot and handles are easy to replace, and its minimal parts and screws make field maintenance simple. Whether deployed for shutdowns, confined space entry, tank cleaning or perimeter protection, the DetectiveIQ delivers continuous, reliable area monitoring with unmatched flexibility.
Key Features
Detect up to 7 gases
PID configuration
Pull in pull out, preconfigured sensor trays
101+ days battery
Crowcon connected app compatibility
Easy to replace parts
30m pump for remote sampling
Gas
Range
Resolution
Methane CH4
0-100% LEL
1% LEL
Carbon Monoxide CO
0-1000ppm
1ppm
Carbon Monoxide CO % H2S
0-1000ppm (CO) 0-100ppm (H2S)
1ppm
Carbon Dioxide CO2
0-5% vol
0.1% vol
Hydrogen Sulphide
0-100ppm
0.1ppm
MPS ATEX – 5pin
0-100% LEL
1% LEL
MPS UL – 5pin
0-100% LEL
1% LEL
Oxygen O2
0-25% volume
0.1% vol
Propane
0-100% LEL
1% LEL
VOC
0-4000ppm
1ppm
Size
298 x536 x268mm
Weight
8.1kg
Material
ASA & Pebax
Response Time (T90)
<20sec
Alarms
Visual, vibrating, audible (95dB at 30cm), low/high, TWA, STEL
Display
Colour LCD Display
Data Logging
Up to 8640 event logs
Power and Battery
101+ days
Sampling
Up to 30m sampling with optional pump
Operating Temperature Range
-20 to +55°C
/ -4 to +131°F
Humidity
0-95% RH
Ingress Protection
IP66 & IP68
Calibration & Maintenance
6 monthly calibrations
Accessories
Bump flow plate, Pumped flow plate, Communication cable, Power cable, Water trap & tubing (pumped device kit)
Connectivity
Bluetooth® & Mesh for connection to Crowcon Connect App
CROWCON CONNECT
Cloud-hosted web application for safety monitoring and asset management, offering real-time alarms, compliance dashboards, location tracking, device configurations, and essential reporting
Sensors
Electrochemical, IR, MPSTM, Pellistor, PID and Long life O2
Warranty
2 Years (separate sensor warranty)
Approvals
CSA US: Class I, Division 1, Groups A, B, C, D, Ex ia da IIC T4 ATEX: Ex II 1G Ex ia da IIC T4 G IECEx: Ex ia da IIC T4 Ga INMETRO: Ex ia da IIC T4 Ga RED/FCC/IC: Wireless
