Flowline LH29 Interstitial Leak Detection Switch

Valox sensor body with PP float and Halar jacketed cable for corrosive liquids, Flat/low profile sensor with minimal float.

Categories:
Manufacturer:

Features

  • Contact type: (1) SPST reed
  • Pressure: 50 psi (3.44 bar)
  • Contact output: NC (opens on rise)
  • Process temp.: -40 to 221°F (-40 to 105°C)
  • Contact state: NC, Open on rise
  • Float material: Foamed polypropylene
  • Body material: Valox 420
  • Applications with limited space and corrosive liquids
  • Pivot pin: Stainless steel
  • Wire type: 2 conductor, #22 AWG
  • Wire length: 10’ (3.04m)
  • Wire jacket material: Halar jacketed
  • Contact rating: 30 watts
    • 240 VAC (0.14 amps resistive)
    • 120 VAC (0.28 amps resistive)
    • 120 VDC (0.07 amps resistive)
    • 24 VDC (0.28 amps resistive)
