ToxiRAE Pro (PGM-1860) Sulfur Dioxide (SO2) Non-Wireless

ToxiRAE Pro (PGM-1860) Sulfur Dioxide (SO2) Non-Wireless Gas Detector
The ToxiRAE Pro from RAE Systems is reliable and intrinsically safe.  It’s ideal for applications and industries such as agriculture, chemicals, fire service/hazmat use, oil and gas, pharmaceutical, pulp and paper, steel manufacturing and water and wastewater.
It’s a single gas detector suitable for monitoring Sulfur Dioxide and a wide range of other toxic gases.  Over 20 intelligent interchangeable sensors are available.  They’re easy to change and able to store calibration data.
You can have confidence that the ToxiRAE Pro will carry out SO2 gas detection safely with its rugged housing and secure alligator clip.
Please note that non-wireless models cannot be upgraded to wireless.

Key Features

A button press or alarm will activate the white LED backlighting on the graphical LCD screen
Gas concentrations in ppm, battery status, data logging on/off, wireless on/off and reception quality – STEL, TWA and peak values will display on screen
Continuous datalogging capacity (three-months at 1 minute intervals) with user-configurable datalogging intervals (from 1 to 3600 seconds)
Sensors, filter and Li-ion battery are replaceable and the unit is easily maintainable
Operation and programming are done with use of 2-buttons
Fully automatic bump testing and calibration with the AutoRAE 2 – available from Frontline Safety

Range
0 to 20 ppm

Resolution

0.1 ppm
Size

4.6” x 2.4” x 1.2” (118 x 60 x 30 mm)

Weight
7.76 oz (220g)

Operating Period

>30 hours (normal operation, non-wireless)
Recharge time <4 hours="" through="" charging="" cradle="" (rechargeable="" li-ion="" battery)="">
Sampling
Diffusion
Humidity
0-95% RH non-condensing
Temperature
-4° to 131°F (-20° to 55°C)
IP Rating
IP-65 for dust & water ingress protection
Alarms

• Audible 95dB @ 30cm
• Vibration
• Visible Alarm (flashing bright LEDs)
• On-screen indication of alarm conditions

Hazardous Location Approvals

• CSA – Class I, Division 1, Groups A, B, C and D, T-code T4, Class I, Zone 0 A/Exia IIC T4
• ATEX – CE II 1G, Ex ia IIC Ga T4
• IECEx – Ex ia IIC Ga T4
• China Ex: Ex ia IIC T4

CE Compliance (European Conformity)
EMC directive 2004/108/EC, R&TTE directive: 1999/5/EC, ATEX directive 94/9/EC

Warranty
2 years on non-consumable components; 1 year on sensor, battery and other consumable parts

What’s Included

• ToxiRAE Pro Monitor with sensor as specified, alligator clip, protective rubber boot, rechargeable battery installed
• Charging and PC communication cradle
• PC Communication Cable
• AC adapter (100 to 240 V, 50/60 Hz AC to 12 V DC)
• Calibration adapters
• Quick Start Guide
• CD with documentation
• ProRAE Studio II software for PC-based instrument configuration and data management
• Calibration card, quality certificate and warranty/registration card
